Product Description:
Pre Packaged ASTM Sacrificial High Potential Magnesium Anode
Specifications
Our High Potential HP Magnesium anodes are made from high-purity
magnesium and have superior electrochemical properties compared to
conventional magnesium anodes. These anodes are suitable for use in
structures buried in soils with resistivities exceeding 2,000
ohm/cm. In practical use, they provide most powerful protection to
the targeted structure. The anodes are also consumed uniformly,
thus providing a longer working life.
All of our magnesium anodes are manufactured and tested according
to the latest international standards, such as ASTM B843 and ASTM
G97. We offer both M1C (high Potential) and AZ63B (standard
Potential) magnesium anodes.
Application
Our High Potential HP Magnesium anodes are effective and economical
in fighting corrosion and are commonly used in marine environments,
soil environment, and more. They protect a range of steel
structures in saltwater, brackish water, and freshwater. These
structures include buried oil and gas pipelines, storage tanks,
boats, ballast tanks, bulkheads, pilings, heat exchangers, and
more.
Magnesium anodes corrode much more easily than the materials they
protect, drawing the corrosion away from equipment.
Chemical compositions of High Potential HP Casting Magnesium Anode
| Type | Al (Max) | Mn | Cu (Max) | Ni (Max) | Si (Max) | Fe (Max) | Single impurity (Max) | Total Impurity (Max) | Mg |
|---|
| M1C | 0.01 | 0.5-1.3 | 0.005 | 0.001 | 0.05 | 0.01 | 0.05 | 0.3 | Remaining |
Electrochemical properties of High Potential HP Casting Magnesium
Anode
| Type | Open-circuit voltage (-V) | Close-circuit voltage (-V)Zn | Actual capacitance (A·h/kg) | Current efficiency (%) |
|---|
| M1C | 1.70-1.75 | 1.58-1.62 | ≥1100 | ≥50 |
* We can customize the size and requirements according to your
needs.
Structure & Dimension
Our Pre Packaged ASTM Sacrificial High Potential Magnesium Anode is
just one of many specifications we offer. We also manufacture
anodes with special shapes, sizes, and chemical compositions upon
request. Please contact us to learn more.
Features:
- Product Name: Sacrificial Anode
- Availability: Widely Available In The Market
- Chemical Composition: Magnesium Anode
- Keyword: CAST Mag Anode
- Content: AZ /HP Alloy
- Type: D Type/S Type/R Type/special Type
Our Sacrificial Anode product is widely available in the market and
is perfect for use in Anode and Cathode Material Furnaces. The
chemical composition of our anodes is Magnesium, making them highly
effective for protecting metal surfaces from corrosion. Our CAST
Mag Anode is made from AZ/HP Alloy, which provides excellent
durability and longevity.
Our D Type, S Type, R Type, and special Type anodes are suitable
for a wide range of applications, including heat pump water heater
tank powered MMO titanium anode. So, whether you're looking for
anodes for industrial or residential use, our Sacrificial Anodes
are the perfect solution.
Technical Parameters:
| Ability | 1 Lbs | 9 Lbs | 17 Lbs | 20 Lbs | 32 Lbs | 60 Lbs |
|---|
| Grade | High Potential / Standard Potential | High Potential / Standard Potential | High Potential / Standard Potential | High Potential / Standard Potential | High Potential / Standard Potential | High Potential / Standard Potential |
|---|
| Usage | Corrosion Protection | Corrosion Protection | Corrosion Protection | Corrosion Protection | Corrosion Protection | Corrosion Protection |
|---|
| Installation | Easy To Install | Easy To Install | Easy To Install | Easy To Install | Easy To Install | Easy To Install |
|---|
| Manufacture | High Broad Co. | High Broad Co. | High Broad Co. | High Broad Co. | High Broad Co. | High Broad Co. |
|---|
| Keyword | CAST Mag Anode | CAST Mag Anode | CAST Mag Anode | CAST Mag Anode | CAST Mag Anode | CAST Mag Anode |
|---|
| Anode Wire | 10mm2 / 16mm2 / AWG/ THHW | 10mm2 / 16mm2 / AWG/ THHW | 10mm2 / 16mm2 / AWG/ THHW | 10mm2 / 16mm2 / AWG/ THHW | 10mm2 / 16mm2 / AWG/ THHW | 10mm2 / 16mm2 / AWG/ THHW |
|---|
| Content | AZ / HP Alloy | AZ / HP Alloy | AZ / HP Alloy | AZ / HP Alloy | AZ / HP Alloy | AZ / HP Alloy |
|---|
| Type | D Type/S Type/R Type/special Type | D Type/S Type/R Type/special Type | D Type/S Type/R Type/special Type | D Type/S Type/R Type/special Type | D Type/S Type/R Type/special Type | D Type/S Type/R Type/special Type |
|---|
| Size | Various Sizes Available | Various Sizes Available | Various Sizes Available | Various Sizes Available | Various Sizes Available | Various Sizes Available |
|---|
Applications:
The sacrificial anode is available in various sizes, making it
suitable for a wide range of applications. It is widely available
in the market, and customers can order the product in bulk
quantities, with a minimum order quantity of 100 kgs. The price of
the product will vary depending on the order quantity, and
customers can choose from different payment terms such as T/T, L/C,
D/P, and Paypal.
The product is easy to install, and customers can easily set it up
without any special skills or tools. The sacrificial anode can be
used in a variety of applications, including marine, offshore, and
industrial environments. It is particularly useful in environments
where metal structures are exposed to corrosive elements, such as
seawater or chemicals.
One of the key features of the High Broad ANODES is its chemical
composition, which is made of magnesium. Magnesium is a highly
reactive metal that has a high potential to corrode. This means
that when a magnesium anode is connected to a metal structure, it
will corrode before the metal structure does, thereby protecting it
from corrosion. This process is known as cathodic protection.
Another important feature of the High Broad ANODES is its
compatibility with bridge rectifier diodes and general-purpose
rectifier diodes. This means that customers can use the sacrificial
anode in conjunction with these devices to ensure optimal
performance and protection.
The sacrificial anode is packaged on pallets, making it easy to
transport and store. Customers can expect delivery within 14-20
days, and the product has a supply ability of 5000 mt/month,
ensuring that customers can always get the product when they need
it.
In conclusion, the High Broad ANODES is a highly effective
sacrificial anode that is suitable for a wide range of
applications. Its extruded magnesium anodes, easy installation, and
compatibility with bridge rectifier diodes and general-purpose
rectifier diodes make it an ideal choice for customers looking for
a reliable and efficient corrosion protection solution.
Customization:
Brand Name: High Broad
Model Number: ANODES
Place of Origin: Hunan China
Certification: ISO, SGS
Minimum Order Quantity: 100 kgs
Price: as per order quantity
Packaging Details: on pallet
Delivery Time: 14-20 days
Payment Terms: T/T, L/C, D/P, Paypal
Supply Ability: 5000 mt/month
Chemical Composition: Magnesium Anode
Standard: ASTM/ISO
Content: AZ/HP Alloy
Size: Various Sizes Available
Product Technology: SUBSEA/UNDERGROUND STEEL PIPES
Keywords: Anion Chip Sanitary Pad, Anode And Cathode Material
Furnace, Anode Supported SOFC
Support and Services:
The Sacrificial Anode product is designed to provide corrosion
protection to metal structures and components. Our technical
support team is available to assist with any questions related to
installation, maintenance, and troubleshooting of the product. We
also offer a range of services including anode replacement,
cathodic protection system design, and corrosion testing to ensure
optimal performance of the sacrificial anode. Contact us for more
information on our technical support and services.
Packing and Shipping:
Product Packaging:
Each sacrificial anode is individually packaged in a protective
plastic sleeve to prevent damage during shipping and storage.
Multiple anodes are then packaged in a sturdy cardboard box with
cushioning material to ensure safe transport.
Shipping:
We offer both domestic and international shipping options for our
sacrificial anodes. Orders are processed within 1-2 business days
and shipped via standard ground shipping. Expedited shipping
options are also available at an additional cost. Shipping costs
will vary depending on the destination and the weight of the
package.
FAQ:
Q: What is the brand name of this sacrificial anode product?
A: The brand name is High Broad.
Q: What is the model number of this sacrificial anode product?
A: The model number is ANODES.
Q: Where is this sacrificial anode product manufactured?
A: It is manufactured in Hunan, China.
Q: What certifications does this sacrificial anode product have?
A: It has ISO and SGS certifications.
Q: What is the minimum order quantity for this sacrificial anode
product?
A: The minimum order quantity is 100 kgs.
Q: What are the payment terms for this sacrificial anode product?
A: The payment terms are T/T, L/C, D/P, and Paypal.
Q: What is the price of this sacrificial anode product?
A: The price is as per order quantity.
Q: What are the packaging details for this sacrificial anode product?
A: The packaging details are on pallet.
Q: What is the delivery time for this sacrificial anode product?
A: The delivery time is 14-20 days.
Q: What is the supply ability for this sacrificial anode product?
A: The supply ability is 5000 mt/month.
