Hot Selling AZ31B Magnesium Anode Rod For Electric Gas Hot Water Heater Steel Tanks Anti Corrosion

1. Technology :

Extruded Magnesium Anode

Cast Magnesium Anode

2. Standard: ASTM B 843-1995

3. Features :

Magnesium anode is used in technical method of electrochemistry cathode protection. theory is from that connect with the protected metal body ,with the exhausting and dissolving of negative metal material or alloy ,protective curer body will be protected from corrosion . Mg anode can produce higher quality potential power, is ideal sacrificial anode materials.

When the potential polarity is reversed, it becomes a cathode, which will accelerate the corrosion of steel. Secondly, the zinc alloy anode will undergo intergranular corrosion in high-temperature water, causing the crystal grains to fall off directly without generating a protective current, resulting in a decrease in current efficiency. Aluminum-based alloy sacrificial anodes are generally used in seawater media, and are rarely used in fresh water, especially in water heaters. The United States has developed 8020 and K804 aluminum alloy sacrificial anodes used in fresh water, but has not been widely promoted and applied. At the same time, it has been found in medicine that the accumulation of aluminum in the brain is related to Alzheimer's disease. Therefore, the aluminum sacrifice of this alloy Anodes are rarely used in water heaters. 1.2 The sacrificial anode materials commonly used abroad for volumetric water heaters are AZ63 and AZ31 series of magnesium alloys with ultra-low impurity content in the ASTM B843-93 standard. Their typical chemical composition is AZ63: A1 5.3%～6.7%, Zn 2.5%～ 3.5%, Mn 0.15%min point 0.6%, Fe 0.003%max, Cu 0.02%max, Ni 0.001%max, Si 0.1%max, AZ31: A12.5%～3.5%, Zn 0.7%～1.3%, Mn 0.2 %Min, Fe 0.002%max, Cu 0.015max, Ni 0.001%max, Si 0.1%max. The above alloy has an open circuit potential of -1.55V to -1.65V and a current efficiency of 53.3 to 60% in hot water of 20 to 80.

China Hunan High Broad New Material was founded in 2006, focus on the business in advanced new material and service. Including: design, installation, material , engineering, maintenance and technical support.

Our sales office located in Changsha, Hunan province, plant located in Hunan,Shanxi, Henan,Guizhou province.Our business scope including : Cathodic protection products for fresh water and marine anti-corrosion products such as magnesium anodes,Aluminum anodes ,Zinc anodes etc.;Master alloy for aerospace ; Aluminum alloy , Magnesium investment castings industry; Magnesium alloy profile :Extrusion/hot rolled billet, plates,bars etc .for various civil & military industry,such as grade AZ31B,AM80,WE43,ZK60 etc.; high wear-resistance & hardness ceramic products for sandblasting nozzle & bulletproof plate for armor vest, armor vehicle.

Along with strong economic development  in China, we expand our business very well, Product capacity is over 5000mt per year.Turnover reach to USD20,000,000.00 per year.

Our Products are widely accepted and recognized by clients worldwide including Europe, North America, East Asia, Middle east etc..

Our R&D department have strong technical design capacity. We closely cooperated with colleges and universities, supply the service for various companies in China and overseas.

Believe we can be your long term and reliable supplier .
