Extruded Magnesium Anode Rod For Water Heater M6 20x250 AZ31B Mg
Rod Photovoltaic Modules Premium Solar Module
We are professional manufacturer and has twenty years experience in anti
corrosion industry. Our main products includes
- Magnesium casting & Extruded Anode, Magnesium Ribbon anode
- Aluminum Anode
- Zinc anode, Zinc Ribbon Anode,
- High Silicon Cast-Iron Anode
- Epoxy Coated Steel Reinforcing Bar
- Ant-corrosion Tapes
Q.What information will be needed if I want a quotation?
A: Materials contents(Chemical Compositions) and the size of
models. Special structures with drawing, Qty and delivery time.
Q. Can we visit your company/factory before place the order?
A: Welcome to visit us in China. Hopefully it will be a happy
journey here.
Q: How does your factory do regarding quality control?
A: Quality is base of the company life. We working on new materials
industrial for more than 20 years.
Q. What do Magnesium sacrificial anodes do?
A. Magnesium anode is used in the technical method of
electrochemistry cathode protection. theory is from that connect
with the protected metal body ,with the exhausting and dissolving
of negative metal material or alloy ,protective curer body will be
protected from corrosion . Mg anode can produce higher quality
potential power, is ideal sacrificial materials.
Basically you can divide hot water storage tanks into five types
classes. Thereto the assembly of the anodes in the different types
of hot water storage tanks is presented:
Typ 1 - Small tank (Electric wall storage heater 30 to 150 litres)
- The anode can be unscrewed through the flange opening
- A new anode (often with a M8 bolt) is fitted by means of hole
mounting.
Typ 2 - Standard tank enamelled up to 1000 litres
- Part of the anode can be unscrewed through the flange opening
- The heat register is mounted firmly
- The anode is mounted in the upper third of the tank (e.g.
connection G 5/4“ with signal anode)
- At double walled tanks for heated water flow the anode will be
mounted in the lid of the hand opening
Typ 3 - Medium tank enamelled (standing or lying), 1000 to 2500
litres
- The heat register is mounted firmly in the factory (do not remove
during maintenance)
- The anodes are mounted in the accumulator head through weld
joints or push-in sockets
- Larger cleaning opening (flange)
Typ 4 - Large tank made out of steel (standing or lying), above
2500 litres
- The anodes are being welded in
- The heat register can be extended during maintenance
Typ 5 - Large tank made out of steel (lying), above 2500 litres
- The anodes is being welded in
- The weld joints are located in the tank front wall
- The anodes are installed horizontally
The heat register will be removed during maintenance
Vivian Jiang(Ms.)
-----------------------------------------------
China Hunan High Broad New Material Co.Ltd.
70 Chezhan North Road,Changsha, China 410100
Tel:+86-731-85717705 Fax:+86-731-85716569
Mobile/Whatsapp: +86-139-7488-3816
Email: metal@vip.163.com, vivian@hbnewmaterial.com
| The universal signal anode can be used as a signal anode or
standard anode. It will be delivered with a M8 bolt together with a
suitable adapter. Thus it is possible to decide flexible on-site
which model is required. Standard models we can offer:| Dimension of Signal Anode | Order Model | | D21 x 310 mm | M8-Einschraubteil / G 3/4” Adapter | | D21 x 500 mm | M8-Einschraubteil / G 3/4” Adapter | | D21 x 700 mm | M8-Einschraubteil / G 3/4” Adapter | | D26 x 500 mm | M8-Einschraubteil / G 1” Adapter | | D26 x 700 mm | M8-Einschraubteil / G 1” Adapter | | D33 x 500 mm | M8-Einschraubteil / G 5/4” Adapter | | D33 x 800 mm | M8-Einschraubteil / G 5/4” Adapter |
Chain Anode| Dimension of Signal Anode | Order Model | | D 21 x 980 mm, 5 Glieder | M8-Einschraubteil / G 3/4” Adapter | | D 33 x 1020 mm, 5 Glieder | M8-Einschraubteil / G 5/4” Adapter |
Further dimensions on requestAll universal signal anodes will be individually packed in cartons
and delivered with nuts, seal, washer, installation information and
signal element. |
