AZ31 Magnesium Engraving Plate for photoengraving

AZ31B is a wrought magnesium base alloy with good room-temperature strength and ductility combined with corrosion resistance and weldability. Increased strength is obtained by strain hardening with a subsequent partial anneal (H24 and H26 tempers).

Product Name	China manufacture foglio di magnesio placa az31 zk60a t5 az91d aluminum magnesium alloy magnesium alloy plate sheet
Standard	AMS/ASTM/JIS/BS/ISO
Brand	AZ31B/ZK60A/AZ91D/AZ61A/AZ40M/AZ41M/AZ80A
Thickness	0.3mm-200mm
Width	customized Max.width 3000mm
Length	Customized
Lead time	3 to 25 working days
Packing	Wooden pallet or according to customer's request

CHEMICAL COMPOSITION

Al: 2.5-3.5%; Zn: 0.7-1.3%; Mn: 0.20 – 1.0%; Mg: Balance

PHYSICAL PROPERTIES

Density: 1.78

Coefficient of thermal expansion: 26.8 x 10-6K-1

Specific heat: 1040 Jkg-1k-1

Thermal conductivity: 76.9Wm-1k-1

Electrical resistivity: 92nΩm

Modulus of elasticity: 45 x 109Pa

Poissons ratio: 0.35

Melting range: 566 - 632°C

APPLICATIONS

Sheet and plate in AZ31B find application in medium strength service at temperatures below 150°C. Diverse uses including aerospace, aircraft, concrete tools, 3C (cell phone / camera / computer), speaker cones and textile machinery can all benefit from light weight AZ31B.

AZ31B is non-magnetic and has high electrical and thermal conductivity filling the requirements for RFI and EMI shielding in the electronics and computer industries.

Superplastic forming of AZ31B sheet at elevated temperatures allows production of a wide variety of intricate parts for automotive uses. Monocoque construction utilizing formed sheet can be adapted to many commercial applications.

Others Magnesium plate

WE43 WE54 WE94 AZ91D AZ31B
