Silicon carbide Sandblasting Nozzles , Shot blasting nozzle with boron carbide material

Ask Lasest Price
Brand Name :	High Broad or OEM
Model Number :	Sand blasting Machine
Certification :	ISO
Price :	negotiable
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal
Supply Ability :	1000 pieces per month
Delivery Time :	200 pieces: 20 days

Add to Cart

Product Details
Company Profile

Silicon carbide Sandblasting Nozzles , Shot blasting nozzle with boron carbide material

Silicon carbide Sandblasting Nozzles , Shot blasting nozzle with boron carbide material

Product Introduction:

High temperature resistance, Abrasion-resistance, light unit weight, working life much longer than tradition material.

Material Comparation Chart:

Item	Al2O3	SiC	B4C
Density	3.5g/cm3	3.1g/cm3	2.4-2.65g/cm3
Hardness	HV1650	HV2750	HV3300
Flexural strength	290 Mpa	380 Mpa	400-650 Mpa
Compressive strength	850 Mpa	3970 Mpa	4100 Mpa
Fracture toughness	4.8 Mpa.m1/2	4.0 Mpa.m1/2	4.5-7.0 Mpa.m1/2
Thermal Conductivity	20 m0k	120m0k	29 m0k

Specifications:

Density: 2.40-2.65 g/cm3

Elastic modulus: 510 Gpa

Knoop Hardness: 3300

Flexural strength: 400-650 Mpa

Compressive strength: 4100 Mpa

Fracture toughness: 4.5-7.0 Mpa.m1/2

Coefficient of thermal expansion: 4.5x106

Thermal Conductivity: 29 m0k

Maximum permissible service temperature in air: 1500℃

Regular size list for straight core

Diameter(mm)	Diameter (mm)	Length(mm)
20	4	45
20	6	45
20	8	45
20	10	45

Diameter(mm)	Diameter (mm)	Length(mm)
20	6	60
20	8	60
20	10	60

Diameter(mm)	Diameter (mm)	Length(mm)
20	6	80
20	8	80
20	10	80

Diameter(mm)	Diameter (mm)	Length(mm)
21	8	82
21	10	82
21	12	82

Other sizes:

Diameter(mm)	Diameter (mm)	Length(mm)
15	6	55
15	8	55
25	8	60
25	10	60
25	12	60
30	8	40
30	10	40
30	12	40
30	14	40

Venturi type:

Coarse thread and Fine thread

Boron carbide nozzle insert with Aluminum or stainless steel jacket

Entrance width	Entrance depth	Bore	Exit	Length
32	40	6.5	10.5	135
32	45	8.0	12.0	150
32	48	95.	14.0	165
32	52	11.0	15.5	190
32	58	12.5	17.0	215
Entrance width	Entrance depth	Bore	Exit	Length
25	28	6.5	10.5	135
25	35	8.0	12.0	150
25	38	95.	14.0	165
25	42	11.0	15.5	190
25	42	12.5	17.0	215

(mm)

Benefits Of Using Boron Carbide:

Longer Life = Reduces Down Time
Lightweight, Reduces User Fatigue (Once you use B4C Nozzles, you won't go back)
Made in the China
Custom Nozzle & Hot Pressing Boron Carbide Manufacturing Available

How to customized nozzles for you ? Pls kindly let us know:

Type of Bore: Straight, Venturi, Wide-Spray, etc.
If threaded, the type of thread required
If Venturi Style, Short Venturi, Long Venturi, Wide Spray?
Flanged, Non-Flanged, or Tapered?
OAL: Overall Length
Bore Size: Diameter of the interior bore
Do you also need a jacket with the nozzle?
