• Item name: Magnesium sacrificial anode

• The advantage: AZ63, High Potential (Mg-Mn) The best quality and best price

• Raw materials: AZ31series,AZ63series and so on

Composition:

HighBroad's magnesium anodes conform in composition to the requirements of U.S. Government Specification MIL-A-21412A (Ships). This 6% aluminum, 3% zinc alloy (AZ-63) usually provides the best combination of economy and operating characteristics in seawater or brackish water.

Galvanic Efficiency:

The current efficiency of HighBroad's magnesium anodes is nominally 55% in seawater and the current capacity is about 550 amp-hr/lb. The open circuit potential of the magnesium alloy used is nominally -1.55 volts to a copper/copper sulfate half cell in seawater; the driving voltage to galvanized steel is about 0.70 volts, providing a relatively high current output per anode. Both hull and condenser anodes are available with a plastisol (polyvinyl chloride) coating which serves as an excellent current barrier shield.

Applications:

Magnesium anodes are effective and economical corrosion fighters that for over 25 years have been protecting a variety of steel structures in salt, brackish and fresh water, including:

• Hulls of ships, barges, tugs and boats
• Ballast tanks of ore carriers and similar vessels
• Bulkheads
• Water storage tanks
• Piers and pilings
• Pipelines
• Heat exchangers
• Travelling screens

We are a professional anode supplier over 16 years ,mainly supply:

* Zinc anodes (ASTM B418-95 US MILL 18001K)

* Al-Zn-In anodes (GAIII)

* Magnesium anodes ( ASTM-G97)

* High silicon cast iron anodes ( ASTM-A518-3,BS1591)

Our anodes are shipped worldwide especial main to North America, Asia etc., around 5000mt per year. Our goods are regularly tested by independent third party lab in USA to keep anode continuous high quality. Our plant owns raw material resources ore, so we can supply very good price with service for you.

We can also accept customized anodes with your logo according to your drawing !

Contact me for more anode information:

China Hunan High Broad New Material was founded in 2006, focus on the business in advanced new material and service. Including: design, installation, material , engineering, maintenance and technical support.

Our sales office located in Changsha, Hunan province, plant located in Hunan,Shanxi, Henan,Guizhou province.Our business scope including : Cathodic protection products for fresh water and marine anti-corrosion products such as magnesium anodes,Aluminum anodes ,Zinc anodes etc.;Master alloy for aerospace ; Aluminum alloy , Magnesium investment castings industry; Magnesium alloy profile :Extrusion/hot rolled billet, plates,bars etc .for various civil & military industry,such as grade AZ31B,AM80,WE43,ZK60 etc.; high wear-resistance & hardness ceramic products for sandblasting nozzle & bulletproof plate for armor vest, armor vehicle.

Along with strong economic development  in China, we expand our business very well, Product capacity is over 5000mt per year.Turnover reach to USD20,000,000.00 per year.

Our Products are widely accepted and recognized by clients worldwide including Europe, North America, East Asia, Middle east etc..

Our R&D department have strong technical design capacity. We closely cooperated with colleges and universities, supply the service for various companies in China and overseas.

Believe we can be your long term and reliable supplier .
