Water Heater Magnesium Anode Rod 3/4in Heating System HVAC .85 x
43.5in x .840
We are uniquely positioned to serve the repair parts needs of RVing
families, whether it's while enjoying weekends outdoors in a small
trailer or traveling full time in a custom coach. Our growing line
of repair parts and expert customer service provides the security
of a trusted, established name to turn to when repair parts are
needed.
Most water heater tanks are steel with a thin glass lining to
protect the metal from corrosion. Since the lining eventually
cracks, tanks have a second line of defense against rust, a long
anode rod that attracts corrosive elements in the water. When the
rod itself becomes so corroded that it can no longer do its job,
the tank soon rusts out, leaks and needs replacement. However, if
you replace your anode rod before it fails, about every 3-5 years(A
magnesium anode), you can double the life of your water heater.
Basically you can divide hot water storage tanks into five types
classes. Thereto the assembly of the anodes in the different types
of hot water storage tanks is presented:
Typ 1 - Small tank (Electric wall storage heater 30 to 150 litres)
- The anode can be unscrewed through the flange opening
- A new anode (often with a M8 bolt) is fitted by means of hole
mounting.
Typ 2 - Standard tank enamelled up to 1000 litres
- Part of the anode can be unscrewed through the flange opening
- The heat register is mounted firmly
- The anode is mounted in the upper third of the tank (e.g.
connection G 5/4“ with signal anode)
- At double walled tanks for heated water flow the anode will be
mounted in the lid of the hand opening
Typ 3 - Medium tank enamelled (standing or lying), 1000 to 2500
litres
- The heat register is mounted firmly in the factory (do not remove
during maintenance)
- The anodes are mounted in the accumulator head through weld
joints or push-in sockets
- Larger cleaning opening (flange)
Typ 4 - Large tank made out of steel (standing or lying), above
2500 litres
- The anodes are being welded in
- The heat register can be extended during maintenance
Typ 5 - Large tank made out of steel (lying), above 2500 litres
- The anodes is being welded in
- The weld joints are located in the tank front wall
- The anodes are installed horizontally
The heat register will be removed during maintenance
