    Continuous Impressed Current Cathodic protection MMO/Ti Linear anodes

    Ask Lasest Price
    Brand Name : High Broad or OEM
    Model Number : ASTM B348 GRADE I/II
    Certification : ISO, DNV,BV
    Price : negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal
    Supply Ability : 30000meters/month
    Delivery Time : 1FCL: 14 days
    • Product Details
    • Company Profile

    Continuous Impressed Current Cathodic protection MMO/Ti Linear anodes

    Continuous Linear anodes,Impressed Current Cathodic protection MMO/Ti Linear anodes


    Mixed Metal Oxide (MMO) and linear anode systems for storage tank soil side corrosion prevention, have long been established as the go-to anode system for corrosion prevention systems. However, the effectiveness of these anodes


      Diameter of flexible anode39+/-2 mm
      Diameter of MMO/Ti anode wire>= 1.0 mm
      Designed service life of anode>= 25 years
      Consumption rate of MMO/Ti anode wire ( with backfill materials)<= 6 mg/A.a
      Output current
      Thickness of metallic oxide coating>= 6 g/m2
      Resistivity of mixed metallic oxides(Ω/cm)10 -5Ω˙cm
      Contact Resistance at the joints between andoe and cable<= 1mΩ
      Resistance of anode<= 0.007 Ω/m
      Carbon content of backfill coke powder>= 98%
      Resistivity of coke powder<= 0.55 Ω˙cm
      Fabric cladding jacket of anodeResistant to acid/alkaline and chlorine; Permeable
      External woven meshResistant to abrasion and ambient temperature variation
      Weight of anode>= 1.3 kgs/meter
      Length of each coil700 meters or customized
